MH-105A Horizontal Automatic Strapping Machine

The MH-105A horizontal automatic strapping machine is an automatic packing equipment for strapping bulk items such as pallets. This machine generally needs to be used in conjunction with the MH-105B pallet strapping machine. The biggest feature of this machine is that there is no need to move the goods, and the frame of the machine moves up and down, then to pack at the corresponding position set in the program, which ensures the packing stability of bulk goods.

Features:
1. PLC control, more stable operation
2. Imported electrical configuration, longer service life
3. Frame operation automatically detects obstacles, making the machine safer and more reliable
4. It can be used as a stand-alone machine or in conjunction with an automated packaging production line
5. Optional automatic alarm device, automatic alarm for missing straps or other fault




Hotline:
+86-757-8540-2680

Product details

Specifications:

Product Code MH-105A
Power 380V, 50/60HZ, 3.1KW, 3PH
Air Pressure 0.4MPa-0.6MPa
Packing Speed ≤15 second/strap
Tension Range 20-250KGS
PP/PET Strap Size Width: 9mm-15mm, Thickness: 0.55mm-1.0mm
Strap Spool Width: 160mm-180mm, Inner Dia.: 220mm-210mm, Outer Dia.: 400mm-500mm
Standard Arch Size W1500mm x H1500mm (Customized)
Machine Dimension 1930mm x 3240mm x 2800mm
Machine Weight 350KGS
