MH-105B Vertical Automatic Strapping Machine

MH-105B vertical automatic pallet strapping machine is specially designed for pallets. The machine has telescopic guide rails. When the machine detects goods, the guide rails will automatically extend to form a closed belt path with the original frame, and then the automatic packaging will be performed.
When one strap is completed, the guide rail will automatically return to the machine body, and then the conveying equipment will transport the items to the next station.

Features：
1. PLC control, more stable operation
2. Imported electrical configuration, longer service life
3. Frame operation automatically detects obstacles, making the machine safer and more reliable
4. It can be used as a stand-alone machine or in conjunction with an automated packaging production line
5. Optional automatic alarm device, automatic alarm for missing straps or other fault

Hotline:
+86-757-8540-2680

Product details

Specifications:

Product Code	MH-105B
Power	380V, 50/60HZ, 1.6KW, 3PH
Air Pressure	0.4MPa-0.6MPa
Packing Speed	≤15 second/strap
Tension Range	20-250KGS
PP/PET Strap Size	Width: 9mm-15mm, Thickness: 0.55mm-1.0mm
Strap Spool	Width: 160mm-180mm, Inner Dia.: 200mm-210mm, Outer Dia.: 400mm-500mm
Standard Arch Size	W1500mm x H2000mm (Customized)
Machine Dimension	4145mm x 845mm x 2630mm
Machine Weight	350KGS
